Ubiquiti Unifi Dream Machine (UDM) – UniFi Gateway

Ubiquiti Unifi Dream Machine (UDM) – UniFi Gateway

UniFi Dream Machine (UDM) all-in-one gateway + WiFi 5 AP, (4) GbE LAN

The Ubiquiti UniFi Dream Machine (UDM) is a compact all-in-one networking solution that simplifies powerful enterprise-grade networking for homes, offices, and small businesses. It integrates multiple UniFi features in a single device — combining a high-speed security gateway, advanced dual-band Wi-Fi access point, managed Gigabit switch, and the UniFi Network Controller.

Product Highlights:

• All-in-One Network Solution: Combines the functionality of a UniFi Gateway and a high-performance WiFi 5 access point to offer comprehensive network coverage.
• UniFi Network Integration: Includes the UniFi Network application for streamlined device management, allowing easy configuration, monitoring, and maintenance of your network.
• Gigabit Connectivity: Features full Gigabit routing with four GbE RJ45 LAN ports for high-speed wired connections, ensuring that your network can handle demanding data transfers and internet speeds.
• Advanced Wireless Technology: Employs built-in WiFi 5 technology to provide expansive wireless coverage and support for multiple devices, delivering top-tier internet speeds and connectivity.

Technical Specifications:

• Mechanical Design: A sleek, cylindrical form factor measuring Ø110 x 184.1 mm (Ø4.3 x 7.3″) with a weight of 1.1 kg (2.3 lb), encased in durable polycarbonate.
• Powerful Hardware: Powered by a quad-core Arm® Cortex® A57 processor at 1.7 GHz with 2 GB DDR RAM, it ensures swift and efficient network operations.
• Versatile Networking Interface: Offers four GbE RJ45 LAN ports for local networking and one GbE RJ45 WAN port for broadband connectivity, alongside Ethernet and Bluetooth management interfaces.
• Robust Power Supply: Features a universal AC input (100—240V AC), an internal 50W AC/DC power supply, and supports a wide voltage range with a maximum power consumption of 26W.

Enhanced Features for Superior Performance:

• Next-Generation Security: With application-aware firewall rules, signature-based IPS/IDS, and content filtering, the UDM provides comprehensive protection for your network.
• Advanced Networking Capabilities: Includes license-free SD-WAN, VPN support (WireGuard, L2TP, OpenVPN), customizable DHCP server, and IPv6 ISP support, ensuring a flexible and secure network configuration.
• High-Performance WiFi: Leverages MIMO technology for improved bandwidth and efficiency, offering throughput rates of up to 300 Mbps on 2.4 GHz and 1.7 Gbps on 5 GHz, with significant antenna gain for extended range.

The Ubiquiti UniFi Dream Machine is a testament to cutting-edge networking technology, designed to meet the needs of today’s dynamic and high-demand network environments. Whether for home use, small businesses, or enterprise applications, the UDM provides a robust, scalable, and secure networking solution that is both powerful and easy to manage. Experience the future of networking with the UniFi Dream Machine, where performance, security, and simplicity converge.
