Ubiquiti UniFi Switch – 48 Ports Managed (US-48-500W)
The Ubiquiti UniFi Switch – 48 Ports Managed (US-48-500W) is a high-performance enterprise Layer 2 managed switch designed to deliver reliable, scalable, and centralized network connectivity for businesses, campuses, and data-intensive environments. Featuring 48 Gigabit Ethernet ports, 2 Gigabit SFP ports, 2 10G SFP+ uplink ports, and a generous 500W PoE budget, this switch is ideal for powering UniFi Access Points, IP cameras, VoIP phones, and other PoE-enabled devices.
Managed seamlessly through the UniFi Network Controller, the Ubiquiti UniFi Switch – 48 Ports Managed (US-48-500W) offers advanced network management features such as VLAN support, Quality of Service (QoS), Link Aggregation, Spanning Tree Protocol (STP/RSTP), and comprehensive monitoring from a single dashboard. Its robust 1U rackmount design ensures easy deployment in server rooms, enterprise networks, schools, hotels, healthcare facilities, and surveillance installations.
Built for performance and reliability, this managed switch provides high switching capacity and non-blocking throughput to support bandwidth-intensive applications while maintaining stable and secure network operations.
Key Features
- 48 × 10/100/1000 Mbps Gigabit RJ45 Ethernet ports
- 500W total PoE power budget
- IEEE 802.3af/at PoE+ support
- 24V Passive PoE support on compatible ports
- 2 × Gigabit SFP fiber uplink ports
- 2 × 10G SFP+ high-speed uplink ports
- Layer 2 managed switch
- Centralized management via UniFi Network Controller
- VLAN, QoS, STP/RSTP, and IGMP Snooping support
- Link Aggregation (LACP)
- Non-blocking switching architecture
- Rack-mountable 1U metal chassis
- Quiet and reliable enterprise operation
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Ubiquiti UniFi Switch – 48 Ports Managed |
| Model | US-48-500W |
| Switch Type | Layer 2 Managed Switch |
| Ethernet Ports | 48 × 10/100/1000 Mbps RJ45 |
| PoE Standard | IEEE 802.3af/at PoE+ |
| Passive PoE | 24V Passive PoE (Supported) |
| Total PoE Budget | 500W |
| SFP Ports | 2 × 1G SFP |
| SFP+ Ports | 2 × 10G SFP+ |
| Switching Capacity | 140 Gbps |
| Non-Blocking Throughput | 70 Gbps |
| Forwarding Rate | 104.16 Mpps |
| MAC Address Table | 16,384 Entries |
| VLAN Support | Yes |
| Link Aggregation | LACP |
| QoS | Supported |
| Spanning Tree | STP, RSTP |
| Management | UniFi Network Controller |
| Mounting | 1U Rack Mount |
| Power Input | 100–240V AC, 50/60Hz |
| Operating Temperature | -5°C to 40°C |
| Dimensions | 485 × 374.6 × 43.7 mm |
| Weight |
Applications
- Enterprise Networks
- Office Buildings
- Educational Institutions
- Hotels and Hospitality
- Hospitals
- Surveillance Systems
- Data Centers
- Retail Stores
- ISP Network Infrastructure
- Large UniFi Deployments
Why Choose the Ubiquiti UniFi Switch – 48 Ports Managed (US-48-500W)?
- Centralized cloud-based UniFi management
- Large 500W PoE budget for powering multiple devices
- High-speed 10G SFP+ uplinks
- Reliable enterprise-grade performance
- Easy integration with the UniFi ecosystem
- Scalable solution for growing business networks
- Advanced security and traffic management features
The Ubiquiti UniFi Switch US-48-500W is a fully managed, PoE+ capable, Layer 2 switch that delivers robust performance and intelligent switching for growing networks. It offers 48 Gigabit Ethernet ports, providing high throughput and robust connectivity. This switch is ideal for deployment in SMBs (Small and Medium-sized Businesses) or enterprise environments, where reliable and efficient network performance is crucial.
