Vertiv Liebert GXT5 1ph UPS, 8kVA, input plug – hardwired, 5U, output – 230V, hardwired, output socket groups (4)C13 & (4)C19
- Description
- Input plug – hardwired,
- 5U, Output – 230V,
- Hardwired, output socket groups (4)C13 & (4)C19
Liebert™ GXT5 UPS is an online double conversion UPS solution which offers premium power outage protection and continuous power conditioning in a compact and flexible deployment system. It protects critical equipment from all power disturbances due to blackouts, brownouts, saps, surges or noise interference. Scalable runtime option with matching auto-detection external battery cabinets offer additional flexibility when extended uninterrupted power is required. User friendly LCD interface as well as full network management capability, including configuration and remote updates, make this system easy to deploy and simple to maintain. With market leading efficiency and unity power factor operation, the Liebert™ GXT5 will fill your critical applications needs.
- Technical Data
Power Output voltage regulation 3% Output power factor 1 Input power factor 0.99 Output power 8000 W Input operation voltage (min) 176 V Input operation voltage (max) 288 V Output operation voltage (min) 230 V Output operation voltage (max) 240 V Efficiency 95% Emergency Power Off (EPO) Yes Power factor 1 Output power capacity 8000 VA Efficiency (On-line mode) 95% Single-phase input voltage supported 220,230,240 V Battery Battery type VRLA Number of batteries supported 16 Battery voltage 12 V Battery capacity 9 Ah Battery technology Sealed Lead Acid (VRLA) Typical backup time at half load 9.5 min Typical backup time at full load 3.5 min Hot-swap battery Yes Battery recharge time(90%) 5 h Performance UPS topology Double-conversion (Online) Waveform Pure sine Number of output phases 1 Number of input phases 1 Power protection features Overload Noise level 55 dB Audible alarm(s) Yes Overload capacity (1 minute) 150% Overload capacity (5 minute) 125% Features Output frequency 50/60 Hz UPS topology Double-conversion (Online) Waveform Pure sine Output voltage regulation 3% Number of output phases 1 Number of input phases 1 Output power factor 1 Input power factor 0.99 Output power 8000 W Input operation voltage (min) 176 V Input operation voltage (max) 288 V Output operation voltage (min) 230 V Output operation voltage (max) 240 V Efficiency 95% Emergency Power Off (EPO) Yes Power protection features Overload Power factor 1 Noise level 55 dB Audible alarm(s) Yes Output power capacity 8000 VA Overload capacity (1 minute) 150% Overload capacity (5 minute) 125% Efficiency (On-line mode) 95% Single-phase input voltage supported 220,230,240 V Input frequency 50/60 Hz Ports & interfaces USB port Yes AC outlets quantity 8 AC outlet(s) AC outlet types C13 coupler,C19 coupler,IEC 320,Terminal Serial ports quantity 1 RS-232 ports 1 Design International Protection (IP) code IP20 Rack capacity 5U Form factor Rackmount/Tower Product colour Black Safety IEC62040-1:2008 Display LCD Cooling type Active Certification CE, EMI/EMC/C-Tick EMC, ESD RoHS compliance Yes Operational conditions Operating temperature (T-T) 0 – 40 C Storage temperature (T-T) -15 – 40 C Operating relative humidity (H-H) 0 – 95% Storage relative humidity (H-H) 0 – 95% Operating altitude 0 – 3000 m Technical details Output voltage 230 V Output frequency 50/60 Hz Cooling Cooling type Active Weight & dimensions Weight 74.5 kg Width 430 mm Height 217 mm Depth 630 mm Package width 646 mm Package depth 816 mm Package height 520 mm Package weight 93 kg Packaging data Package width 646 mm Package depth 816 mm Package height 520 mm Package weight 93 kg Certificates Safety IEC62040-1:2008 Certification CE, EMI/EMC/C-Tick EMC, ESD RoHS compliance Yes Other features Output voltage 230 V Battery type VRLA Quick Links
