Ubiquiti Antenna AM-5G19 5Ghz 19dBi 120-deg Dual-Pol Sector
This 5GHz sector is part of the Ubiquiti airMAX line of products. AM-5G19 is designed to work with the Rocket M5, with a 120° beamwidth and 19dBi gain.
The Ubiquiti AM-5G19 is a 5GHz 19dBi dual-polarized sector antenna engineered for high-capacity point-to-multipoint (PtMP) wireless networks. Its 120° coverage angle and dual-polarization design deliver optimal throughput and enhanced network reliability across multiple client devices.
Constructed from durable materials for outdoor deployment, the AM-5G19 ensures robust performance even in harsh weather conditions. It is compatible with Ubiquiti airMAX and other wireless systems, making it a versatile choice for ISPs, enterprise networks, and campus installations.
With precise beam shaping, high gain, and dual-polarization, this antenna maximizes coverage while minimizing interference, providing long-range connectivity and stable high-speed links. The easy mounting hardware allows flexible installation, while its professional-grade design ensures consistent network performance for outdoor wireless applications.
Specifications
| Feature | Details |
|---|---|
| Model | AM-5G19 |
| Frequency | 5 GHz |
| Gain | 19 dBi |
| Beamwidth | 120° horizontal, 14° vertical |
| Polarization | Dual-polarized (Vertical + Horizontal) |
| Connector | N-type female |
| VSWR | ≤1.5 |
| Impedance | 50 Ω |
| Max Power | 100 W |
| Operating Temperature | -40°C to 80°C |
| Dimensions | 362 x 300 x 60 mm |
| Weight | 1.4 kg |
| Application | Outdoor PtMP wireless networks, ISPs, high-density client coverage |
Product Specifications:
• Frequency Range: 5.15-5.85 GHz
• Gain: 18.6-19.1dBi
• Polarization: Dual Linear
• Cross-pol Isolation: 28dB min
• Max VSWR: 1.5:1
• Hpol Beamwidth (6dB): 123deg;
• Vpol Beamwidth (6dB): 123deg;
• Elevation Beamwidth: 4 deg.
• Electrical Downtilt: 2 deg.
• ETSI Specification: EN 302 326 DN2
• Dimensions: 27.6×5.7×3.1in (700x145x79mm) diameter
• Weight: 13.0lbs (5.9kg)
• Windloading: 160 mph
Product Includes:
• Sector Antenna
• Antenna Bracket with the Rocket Fast Mount (for the Airmax BaseStation Model only)
• Pole Brackets, bolts, washers and nuts
• RF Jumper Cables (weatherproof)
