Ubiquiti Access Point WiFi 6 In-Wall U6-IW
The Ubiquiti UniFi Access Point WiFi 6 In-Wall (U6-IW) is a powerful, compact access point that blends seamlessly into any environment. Designed to replace an existing wall outlet, it provides fast dual-band WiFi 6 connectivity and offers multiple Gigabit Ethernet ports for wired device connections.
Powered by 802.11ax WiFi 6 technology, the U6-IW supports high user capacity and advanced features such as OFDMA and MU-MIMO for efficient data transmission in dense network environments. It’s ideal for hotels, offices, apartments, and smart homes seeking a clean installation with both wireless and wired options.
Easily managed via the UniFi Network Controller or UniFi Network Mobile App, this access point ensures simplified deployment, centralized control, and powerful insights into network performance.
Bring next-generation wireless performance to every room with the Ubiquiti Access Point WiFi 6 In-Wall (U6-IW). Designed for discreet, wall-mounted deployment, this dual-band access point transforms an Ethernet wall outlet into a powerful WiFi 6 hub, ideal for hotel rooms, offices, and residential spaces.
In addition to WiFi, the Ubiquiti Access Point WiFi 6 In-Wall (U6-IW) includes four Gigabit Ethernet ports—three for wired devices and one with PoE passthrough to power downstream equipment like VoIP phones or IP cameras.
Wall-mounted WiFi 6 access point with a built-in PoE switch.
- 115 m² (1,250 ft²) coverage
- 300+ connected devices
- WiFi6 (4×4 MIMO)
- Powered using PoE*
Technical Specifications Ubiquiti Access Point WiFi 6 In-Wall U6-IW
| Mechanical | |
|---|---|
| Dimensions | 139.7 x 96 x 31.2 mm (5.5 x 3.8 x 1.3″) |
| Weight | 460 g (1 lb) |
| Enclosure material | Plastic, aluminum |
| Mount material | Aluminum |
| Hardware | |
| Networking interface | (1) Data-in: GbE RJ45 port (4) Data-out: GbE RJ45 ports |
| Management interface | Ethernet Bluetooth |
| PoE interface | (1) PoE in (PoE output not used) (1) PoE out (Requires a PoE+ switch) |
| Power method | PoE PoE+ (Required for PoE output) |
| Power supply | UniFi PoE switch 48V, 0.5A PoE adapter (Optional) |
| Max. power consumption | 13.5W (Excluding PoE output) |
| Max PoE wattage per port by PSE | 15.4W* *Requires a PoE+ switch |
| Voltage range PoE mode | 44—57V DC |
| Max. TX power 2.4 GHz 5 GHz 6 GHz | 22 dBm 26 dBm – |
| MIMO 2.4 GHz 5 GHz 6 GHz | 2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) – |
| Throughput rate 2.4 GHz 5 GHz 6 GHz | 573.5 Mbps 4.8 Gbps |
| Antenna gain 2.4 GHz 5 GHz 6 GHz | 5 dBi 5.9 dBi – |
| LED | White/blue |
| Button | Factory reset |
| Mounting | Wall (Included) |
| Operating temperature | -30 to 60° C (-22 to 140° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| WiFi standards | 802.11a/b/g/n/ac/ax |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Concurrent clients | 300+ |
| Zero-wait DFS | Yes* *Supported with upcoming firmware versions. |
| Supported Data Rates | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n (WiFi 4) | 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40) |
| 802.11ac (WiFi 5) | 6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
| 802.11ax (WiFi 6) | 7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160) |
