MikroTik Cloud Router Switch (CRS317-1G-16S+RM)
The MikroTik CRS317-1G-16S+RM is a high-performance, rack-mounted cloud router switch designed to handle demanding network environments with ease. Equipped with 16 high-speed 10G SFP+ ports and a dedicated Gigabit Ethernet management port, this switch is perfect for enterprise and data center applications where ultra-fast connectivity and advanced management capabilities are essential.
Powered by a dual-core 800 MHz CPU and featuring 1 GB of RAM, the CRS317 delivers powerful Layer 3 switching performance, making it suitable for both simple access and complex distribution layer roles. It runs MikroTik’s flexible RouterOS (License Level 6) and also supports SwitchOS, giving administrators the option to choose between advanced routing features or simplified switch management based on their needs.
This device stands out for its dual redundant power supplies, ensuring continuous uptime and high reliability in mission-critical networks. Passive cooling (with additional intelligent fans) ensures silent and efficient operation even under load.
Whether you’re managing heavy data traffic, creating high-speed fiber uplinks, or deploying a backbone network, the CRS317-1G-16S+RM offers the scalability, speed, and control needed to build a robust and future-proof network infrastructure.
Key Features
16 x 10G SFP+ Ports for ultra-fast fiber connectivity
1 x Gigabit Ethernet port for management access
Dual-core 800 MHz CPU and 1 GB RAM for smooth performance
Supports RouterOS (L6) and SwitchOS for flexible management
Dual redundant power supplies for high availability
Layer 3 features including static routing and VLAN support
Silent operation with intelligent fan cooling
Specifications
Product Code: CRS317-1G-16S+RM
Architecture: ARM 32bit
CPU: 98DX8216, 2 cores @ 800 MHz
RAM: 1 GB
Storage: 16 MB (FLASH)
Dimensions: 443 x 224 x 44 mm
RouterOS License: Level 6
Operating System: RouterOS v7 / SwitchOS
MTBF: Approximately 200,000 hours at 25°C
Operating Temperature: -20°C to 60°C
Powering
AC Inputs: 2
Power Supply Type: Dual redundant
Max Power Consumption: 44 W
Cooling: Passive + 2 intelligent fan Connectivity
Ethernet: 1 x 10/100/1000 Mbps
SFP+: 16 x 10G ports
Console Port: RJ45
Monitoring & Certification
Temperature & Voltage Monitoring: Yes
Certifications: CE, ROHS
IP Rating: IP20
