HP ScanJet Pro 3600f1 Scanner
HP ScanJet Pro 3600f1 Scanner (20G06A)
| Scanner type | ADF; CIS scanning technology; Flatbed |
|---|---|
| Digital sending standard features | Send to USB Drive |
| Digital sending optional features | Send to email; Send to PC |
| Scan resolution, optical | Up to 600 dpi (color and mono, ADF); Up to 1200 dpi (color and mono, flatbed) |
| Scan resolution, hardware | Up to 600 x 600 dpi (color and mono, ADF); Up to 1200 x 1200 dpi (color and mono, flatbed) |
| Enhanced scanning resolution | Up to 1200 dpi
|
| Duty cycle (daily) | Recommended daily duty cycle: 3000 pages (ADF) |
| Bit depth | 24-bit (external), 48-bit (internal) |
| Automatic document feeder scan speed | Up to 30 ppm/60 ipm (b&w, gray and color, 300 dpi)1 |
| Automatic document feeder scan speed | Up to 30 ppm/60 ipm (b&w, gray and color, 300 dpi)1 |
| Scan size (ADF), maximum | 216 x 3100 mm |
| Scan size, maximum | 216 x 297 mm |
| Scan size (ADF), minimum | 89 x 148 mm |
| Automatic document feeder capacity | Standard, 60 sheets |
| Duplex ADF scanning | Yes |
| Scan file format | For text and image pages : PDF, JPEG, PNG, BMP, TIF, Text(TXT), Rich Text(RTF), SEARCHABLE PDF, PDF/A, Word(DOC), Word(DOCX), Excel(XLS), Excel(XLSX), CSV |
| Scan input modes | Scan front-panel function : Save as PDF, Save as JPEG, Scan to E-mail, Send to Cloud and Scan to USB. HP Scan in Win OS, HP Easy Scan/ICA in Mac OS and third parties applications via TWAIN. |
| Color scanning | Yes |
| Levels of grayscale | 256 |
| Image scaling or enlargement range | Will not perform any arbitrary scaling |
| Scan technology | ADF; Flatbed; Contact Image Sensor (CIS) |
| Scanning options (ADF) | Single-pass Duplex scanning |
| Multifeed detection | Yes |
| Output resolution dpi settings | 75; 150; 200; 240; 300; 400; 500; 600; 1200 ppi |
| Light source (scanning) | Light Emitting Diode (LED) |
| Document weight ADF (maximum) | 120 g/m² |
| Media size (ADF) | Letter; Legal; Executive; A4; A5; A6; B5; B5 (JIS) |
| Media types | Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index) |
| Media weights, supported ADF | 49 to 120 g/m² |
| Scanner advanced features | One pass duplex scanning; Multi-feed detection sensor; Configurable Scan shortcuts with HP Scan (included): OCR; Auto exposure; Auto threshold; Auto detect colour; Background smooth/removal; Auto detect size; Straighten content; Enhance content; Auto orient; Multicolour dropout; Edge erase; Blank page options: Delete Blank Page, Blank Page Detection Sensitivity, Zonal Blank Detect; Merge pages; Document separation options: Zonal Text Separation, Barcode Separation, Blank Page Separation (Front/Back/Both/Any side selection), Add Page Separator Manually; Auto Feed; Show Viewer After Scan and Post Scan Operations are: Mark the image for Deletion, Rotate option, Move Left/Right, Create/Delete New Selection, Save as Scan Area, Manual Straighten option, Drag and Crop, Undo Options, image – Basic Zoom Slider, Open in Zoom Window(Zoom, Crop, Rotate) ; Background Clean-up options: Clean-up Background, Remove: make white, Smooth: make consistent, Remove Holes, Multi-Streaming; Single zone Selection for Zonal OCR, Barcode and QR Code; PDF options: PDF Security Settings (Applicable for PDF and Searchable PDF), Password Security & Document Permission Settings, PDF – iHQC compression, File Size/Quality Slider; TIFF Compression Options: for Gray or Color: Uncompressed/LZW/Jpeg-Tiff, for BW: Uncompressed/LZW/Tiff G3/Tiff G4; File Name Options: Base Name, Date, Time, Document Counter, Barcode Value, Zonal Text, File name sequence Settings, If File name already exists Actions – Overwrite/Append Date Time Stamp/Prompt for File Name, Intelligent File Naming; Destinations options: Email (Mail Clients, Save Local Copy Option, Local or NW), Folder, Save Folder path, Show Save as Dialog Box, After Saving the File(s) action, Printer/Fax, Plugins available if not already included: SMTP, SFTP, Box and Evernote, SharePoint, SharePoint365, Google Drive, Dropbox, OneDrive, One Drive for Business and more..; Enable Book Scan (Flatbed); Vertical Streak Removal/Detection; Multi Document Scanning; Enable Desktop Icons creation for Scan Profiles/Shortcuts; Shortcut Management: Create new Scan Shortcut, Delete Shortcut, Rename Shortcut, Shortcut Move Up/Down, Shortcut – Save/Undo, Restore Shortcut Defaults-Factory Settings, Import/Export Shortcut; retrieve shortcuts from Scanner without accessing the software on the PC |
| Compatible Operating Systems | Windows 11; Windows 10; Windows 8; Windows 8.1; Windows 7; Windows Server; macOS 10.14 Mojave; macOS 10.15 Catalina; macOS 11 Big Sur; macOS 12 Monterey; Linux
|
| Mac compatible | Yes |
| Minimum System Requirements for Macintosh | 10.14(Mojave), 10.15(Catalina) and 11.x(Big SUR) Internet required |
| Minimum System Requirements | Microsoft® Windows® (11, 10, 8.1, 7 : 32-bit and 64-bit, 2008 R2, 2012 R2, 2016, 2019); 2 GB available hard disk space, Internet connection, Microsoft® Internet Explorer or any browser |
| Twain version | Version 2.4 |
| Processor speed | 666 MHz |
| Memory | 256 MB |
| Software included | HP Scan Software, HP Scanner Device Driver, HP WIA scan driver, HP TWAIN scan driver, HP Scanner Tools Utility, |
| Connectivity, standard | USB 3.0 |
| Power | Input Voltage: 100 to 240 VAC |
| Power supply type | External power adapter |
| Power consumption | 13.31 watts (Active – Scanning), 5.31 watts (Ready), 1.23 watts (Sleep), 0.07 (Auto-Off), 0.07 (Manual-Off) (Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty.) |
| Control panel | 6 lights (Shortcut, Duplex, Error); 5 button (Power, Scan, Duplex, Shortcut Select, Cancel ) |
| Security management | Power button to on/off |
| Operating humidity range | 15 to 80% RH (non-condensing) |
| Recommended operating humidity range | 30 to 70% RH |
| Non-Operating Humidity Range | 0 to 90% RH (non-condensing) |
| Operating temperature range | 10 to 35°C |
| Operating temperature range | 50 to 95°F |
| Recommended operating temperature range | 17.5 to 25°C |
| Recommended operating temperature range | 63.5 to 77°F |
| Storage temperature range | -40 to 60°C |
| Storage temperature range | -40 to 140°F |
| Acoustic power emissions (active, printing) | 6.5 B(A) |
| Minimum dimensions (W x D x H) | 491.5 x 325.4 x 133.3 mm |
| Maximum dimensions (W x D x H) | 491.5 x 422.28 x 387.42 mm |
| Weight | 5.4 kg |
| Weight | 5.4 kg |
| Package dimensions (W x D x H) | 600 x 245 x 499 mm |
| Package weight | 7.3 kg |
| Ecolabels | CECP; SEPA; IT ECO Declaration; EPEAT® Silver registered2 |
| Energy star certified | Yes |
| Electromagnetic compatibility | Class B Emissions; CISPR 32:2015 (International); European Union EMC Directive 2004/108/EC, EN 55032:2015 (CE mark); China GB9254-2008 (CCC); Taiwan CNS13438:2006 (BSMI); USA CFR47 Part 15, Subpart B (FCC); ICES-003:2020 Issue 7 (Canada); Australia C-tick (includes New Zealand); KN 22 and Korea KCC; EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity 505035:2017 |
| Safety | IEC62368-1:2018, IEC 60950-1:2005 +A1 and all applicable amendments; CSA/UL 60950-1, 2nd edition (2007); EN 60950-1:2006 +A11 +A1 +A12+A2; EAC safety; Canada cUL CoC; China CCC; European Union CE; Kenya PVOC; Kuwait TER; Nigeria SON; Saudi Arabia SASO; South Africa NRCS; Taiwan BSMI; Ukraine safety approval |
| What’s in the box | HP ScanJet Pro 3600 f1 Scanner; Install Guide; Supporting flyers; Cushions; USB cable; Power adapter; Power cords |
| Manufacturer Warranty | One-year limited hardware warranty, phone and Web support included. Warranty may vary by country as required by law. |
Overview
The HP ScanJet Pro 3600f1 Scanner is a versatile and high-performance scanning solution designed to meet the demands of busy offices and professional environments. This advanced scanner combines speed, reliability, and superior image quality, making it an indispensable tool for digitizing documents efficiently and accurately.
The ScanJet Pro 3600f1 features an impressive scanning speed, capable of processing up to 30 pages per minute (ppm) and 60 images per minute (ipm) in duplex mode. This rapid performance ensures that high-volume scanning tasks are completed quickly, significantly boosting productivity. The device supports a daily duty cycle of up to 3,000 pages, making it well-suited for organizations with frequent scanning needs.
Equipped with a robust 50-sheet automatic document feeder (ADF), the ScanJet Pro 3600f1 facilitates smooth and continuous scanning of multi-page documents. This feeder can handle various paper sizes and types, from thin receipts to thick cardstock, providing flexibility for diverse scanning requirements. Additionally, the flatbed scanner allows for the scanning of bound materials, such as books and magazines, ensuring comprehensive document digitization capabilities.
The scanner delivers exceptional image quality with a high optical resolution of up to 1200 dpi, producing sharp, clear, and detailed digital copies of original documents. Advanced image enhancement features, including auto-cropping, orientation correction, and blank page removal, further refine scanned images, ensuring professional results.
User convenience is a key feature of the HP ScanJet Pro 3600f1. The intuitive control panel and one-touch buttons simplify operation, allowing users to initiate common scanning tasks quickly. The scanner is compatible with a range of scanning software, offering seamless integration with existing workflows. It also supports various file formats, including PDF, JPEG, and TIFF, catering to different document management needs.
Security and connectivity are well-addressed with the ScanJet Pro 3600f1. It includes built-in security features to protect sensitive information and offers multiple connectivity options, such as USB 3.0 and Wi-Fi, for flexible and convenient scanning.
In summary, the HP ScanJet Pro 3600f1 Scanner is a high-speed, high-quality, and user-friendly scanning solution ideal for businesses and professional environments. Its advanced features, robust performance, and exceptional image quality make it a valuable asset for efficient document digitization and management.
