APC Smart-UPS C 2000VA Tower (SMC2000I)
Keep your critical systems running with the APC Smart-UPS C 2000VA Tower (SMC2000I)—a reliable, line-interactive UPS designed to protect servers, network hardware, and sensitive electronics. With 2000VA/1600W of clean power and a pure sine wave output, this UPS ensures safe operation during outages, surges, and voltage fluctuations.
Key Features:
Capacity: 2000VA / 1600W
Output: Pure sine wave for full equipment compatibility
Voltage: 230V input/output with AVR (Automatic Voltage Regulation)
Runtime: Approx. 11 mins at half load, 3 mins at full load
Outlets: 6 x IEC C13 & 1 x IEC C19
Display: Intuitive LCD for real-time UPS status and control
Communication Ports: USB and SmartSlot for remote management
Battery Type: Hot-swappable sealed lead-acid battery
Form Factor: Compact tower design, ideal for office or server room use
Features: APC Smart-UPS C 2000VA Tower (SMC2000I).
- Cold-start capableProvides temporary battery power when the utility power is out.
- Green modePatent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High online efficiencyReduces utlility costs, generates less heat.
- LCD Status DisplayProvides key UPS status at a glance. Multiple status indicators with load and battery bar graphs.
- Pure sine wave output on batterySimulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Temperature-compensated battery chargingProlongs battery life by regulating the charge voltage according to battery temperature.
Overview
The APC Smart-UPS C 2000VA Tower (SMC2000I) is a high-performance uninterruptible power supply (UPS) designed to provide reliable and efficient power protection for critical electronic equipment. With a power capacity of 2000 volt-amps (VA) or 1300 watts (W), this UPS is ideal for small to medium-sized businesses, home offices, and network closets.
The SMC2000I is equipped with Automatic Voltage Regulation (AVR) technology that instantly adjusts high and low voltages to safe levels without using the battery, extending the battery life and ensuring continuous operation during voltage fluctuations. This feature is particularly beneficial in environments with unstable power supply, as it minimizes the risk of interruptions and prolongs the overall lifespan of the UPS.
Smart-UPS Features & Benefits
Manageability
- Network manageableProvides remote power management of the UPS over the network.
- Disconnected battery notificationWarns when a battery is not available to provide backup power.
- Serial connectivityProvides management of the UPS via a serial port.
- USB connectivityProvides management of the UPS via a USB port (not available on all models).
- Audible alarmsActively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
- LED status indicatorsQuickly understand unit and power status with visual indicators.
Serviceability
- User-replaceable batteriesIncreases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- Hot-swappable batteriesEnsures clean, uninterrupted power to protected equipment while batteries are being replaced
- Resettable circuit breakersEnables a quick recovery from overload events.
- Predictive failure notificationProvides early-warning fault analysis ensuring proactive component replacement.
- Battery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenance
Adaptability
- Adjustable voltage-transfer pointsMaximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Adjustable voltage sensitivityProvides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Safety
- Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Availability
- Disconnected battery notificationWarns when a battery is not available to provide backup power.
- Automatic restart of loads after UPS shutdownAutomatically starts up the connected equipment upon the return of utility power.
- Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.
- Boost and Trim Automatic Voltage Regulation (AVR)Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.
- Power conditioningProtects connected loads from surges, spikes, lightning, and other power disturbances.
- Temperature-compensated battery chargingProlongs battery life by regulating the charge voltage according to battery temperature
Print Technical Specification
Output
- Output power capacity: 1.3 KWatts / 2.0 kVA
- Max Configurable Power (Watts): 1.3 KWatts / 2.0 kVA
- Nominal Output Voltage: 230V
- Output Voltage Distortion: Less than 5% at full load
- Output Frequency (sync to mains): 50 Hz
- Topology: Line Interactive
- Waveform type: Sine wave
- Output Connections(6) IEC 320 C13 (Battery Backup)(1) IEC 320 C19 (Battery Backup)
Input
- Nominal Input Voltage: 230V
- Input frequency: 47 – 63 Hz
- Input Connections: IEC-320 C20
- Input voltage range for main operations: 180 – 287V
- Input voltage adjustable range for mains operation: 170 – 300V
- Other Input Voltages: 220, 240
Batteries & Runtime
- Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
- Typical recharge time
3hour(s)
- Replacement Battery
- Expected Battery Life (years)
3 – 5
- RBC Quantity
1
- Runtime
Communications & Management
- Interface Port(s)
USB
- Control panel
Multi-function LCD status and control console
- Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
- Emergency Power Off (EPO)
—
Surge Protection and Filtering
- Surge energy rating
300Joules
- Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
- Maximum Height
216mm , 21.6CM
- Maximum Width
170mm , 17.0CM
- Maximum Depth
440mm , 44.0CM
- Net Weight
27.5KG
- Shipping weight
30.0KG
- Shipping Height
330mm , 33.0CM
- Shipping Width
370mm , 37.0CM
- Shipping Depth
590mm , 59.0CM
- Color
Black
- Units per Pallet
24.0
Environmental
- Operating Temperature
0 – 40 °C
- Operating Relative Humidity
0 – 95 %
- Operating Elevation
0-3000meters
- Storage Temperature
-15 – 45 °C
- Storage Relative Humidity
0 – 95 %
- Storage Elevation
0-15000meters
- Audible noise at 1 meter from surface of unit
45.0dBA
- Online thermal dissipation
135.0BTU/hr
Conformance
- Approvals
C-tick, CE, GOST, SABS, VDE
- Equipment protection policy
3 years
- Standard warranty
1 year repair or replace
